600 Ampere MIG Welding Inverter

Three Phase, 600 Ampere, MIG Welding Machine with separate Wire Feeder.

Limah 600 MIG Welding Machine with separate Wire Feeder is suitable for Welding upto 15 mm thick MS and Stainless Steel SS with upto 1.6 mm thick MIG Wire. It gives fine weld seam with almost no spatter. It can also be used in DC Arc Welding MMA mode.

SPECIFICATION

Input power voltage	:    AC380V±15%
Input voltage frequency	:    50/60 Hz
Rated input power	:    35.8 KW
Rated input current	:    54.4 A
Output current range	:    50-630A
Rated output voltage	:    52 V
Duty cycle	:    60%
Efficiency	:    85%
Power factor	:    0.93
Insulation class	:    B
Protection class	:    IP21
Feeding speed	:    2.5-13 m/min
Type of wire feeder	:    External, 4 Roll
Diameter of coil	:    300 mm
Post gas
Earth cable
Thickness	:    above 0.8 mm
Diameter of wire	:    0.8/1.0/1.2/1.6 mm
Weight	:    50 KG
Dimension	:    604×325×614 mm
